Simply put, a single-zone mini split system only allows for one indoor unit to be connected to the condenser (the outdoor unit).
A multi-zone mini split system allows you to connect two (2) or more indoor units to the outdoor condenser, allowing multiple
areas to be cooled or heated!
This can reduce the number of outdoor units required. All indoor units can be individually controlled
and do not need to be installed at the same time.


The first step would be choosing what condenser (outdoor unit) you need.
Then, once you've chosen the outdoor unit, you may mix and match whichever or however many indoor units you would like to connect
to the outdoor condenser.
If you would like to purchase a multi-zone system, please contact us by phone at 818.785.4151
to get in touch with one of our representatives, or stop by at 15041 Calvert St. in the city of Van Nuys, California.



OUTDOOR UNITS

Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Cooling Capacity (Min-Max) : 17,000 (4,197-19,900) Btu/h
Heating Capacity (Min-Max) : 18,000 (2,225-23,475) Btu/h
Power Supply : 208-230V/60Hz
Ambient temperature - Cooling : -13...122 deg F
Ambient temperature - Cooling : -13...86 deg F
Compressor Type : rotary
Sound Pressure Level : 62.4 dB(A)
Unit dimension (WxHxD) : 33.27x14.29x27.64 inches
Net/Gross Weight : 105.82/114.64 lbs
Refrigerant/Charge : R410A/70.5 oz.
Port Size (Liquid - Gas/Suction) : 2x1/4"-2x3/8" inch
Max. length for all rooms : 98 ft
Max. length for one indoor unit : 66 ft
Max. height difference between indoor units : 33 ft
SEER : 21.3

Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Cooling Capacity (Min-Max) : 27,000 (6,630-30,600) Btu/h
Heating Capacity (Min-Max) : 28,000 (3,690-32,860) Btu/h
Power Supply : 208-230V/60Hz
Ambient temperature - Cooling : -13...122 deg F
Ambient temperature - Cooling : -13...86 deg F
Compressor Type : rotary
Sound Pressure Level : 63.4 dB(A)
Unit dimension (WxHxD) : 37.24x16.14x31.89 inches
Net/Gross Weight : 149.91/160.94 lbs
Refrigerant/Charge : R410A/98.8 oz
Port Size (Liquid - Gas/Suction) : 3x1/4"-3x3/8" inch
Max. length for all rooms : 148 ft
Max. length for one indoor unit : 82 ft
Max. height difference between indoor units : 33 ft SEER : 22.0


Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Cooling Capacity (Min-Max) : 36,000 (8,190-38,500) Btu/h
Heating Capacity (Min-Max) : 36,000 (4,940-38,000) Btu/h
Power Supply : 208-230V/60Hz
Ambient temperature - Cooling : -13...122 deg F
Ambient temperature - Cooling : -13...86 deg F
Compressor Type : rotary
Sound Pressure Level : 62.3 dB(A)
Unit dimension (WxHxD) : 37.24x16.14x31.89 inches
Net/Gross Weight : 156.53/167.55 lbs
Refrigerant/Charge : R410A/105.8 oz
Port Size (Liquid - Gas/Suction) : 4x1/4"-3x3/8"+1x1/2" inch
Max. length for all rooms : 197 ft
Max. length for one indoor unit : 98 ft
Max. height difference between indoor units : 33 ft
SEER : 22.5

Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Cooling Capacity (Min-Max) : 48,000 (9,560-53,500) Btu/h
Heating Capacity (Min-Max) : 48,000 (6,850-53,980) Btu/h
Power Supply : 208-230V/60Hz
Ambient temperature - Cooling : -13...122 deg F
Ambient temperature - Cooling : -13...86 deg F
Compressor Type : rotary
Sound Pressure Level : 64 dB(A)
Unit dimension (WxHxD) : 37.48x16.34x52.48 inches
Net/Gross Weight : 101.5/115.7 lbs
Refrigerant/Charge : R410A/162.3 oz
Port Size (Liquid - Gas/Suction) : 5x1/4"-3x3/8"+2x1/2" inch
Max. length for all rooms : 246 ft
Max. length for one indoor unit : 98 ft
Max. height difference between indoor units : 33 ft
SEER : 21.5


INDOOR UNITS

(To go with your outdoor unit)

Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Power Supply : 208-230V/60Hz
Rated Current Cooling : 2.9 A
Rated Current Heating : 4.2 A
Cooling Capacity (Min-Max) : 9,000 Btu/h
Heating Capacity (Min-Max) : 9,800 Btu/h
SEER : 22.8 Btu/w
HSPF4 : 10.5 Btu/w
HSPF5 : 8.6 Btu/w
COP : 3.09 W/W
Air Flow : 265/205/141 CFM
Noise level - Hi/Mi/Lo : 36.5/30/25 dB(A)
Indoor unit dimension (WxHxD) : 31.57x7.44x11.69 inches
Net/Gross Weight : 18.1/22.0 lbs

Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Power Supply : 208-230V/60Hz
Rated Current Cooling : 4.05 A
Rated Current Heating : 4.72 A
Cooling Capacity (Min-Max) : 12,000 Btu/h
Heating Capacity (Min-Max) : 12,000 Btu/h
SEER : 21.5 Btu/w
HSPF4 : 9.8 Btu/w
HSPF5 : 7.7 Btu/w
COP : 3.24 W/W
Air Flow : 306/212/147 CFM
Noise level - Hi/Mi/Lo : 36.5/30/25 dB(A)
Indoor unit dimension (WxHxD) : 31.57x7.44x11.69 inches
Net/Gross Weight : 18.1/22.0 lbs

Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Power Supply : 208-230V/60Hz
Rated Current Cooling : 6.1 A
Rated Current Heating : 6.82 A
Cooling Capacity (Min-Max) : 18,000 Btu/h
Heating Capacity (Min-Max) : 18,000 Btu/h
SEER : 20.8 Btu/w
HSPF4 : 10 Btu/w
HSPF5 : 8 Btu/w
COP : 3.36 W/W
Air Flow : 559/365/306 CFM
Noise level - Hi/Mi/Lo : 43/38/32 dB(A)
Indoor unit dimension (WxHxD) : 42.52x8.90x13.19 inches
Net/Gross Weight : 29.1/37.0 lbs

Sophia Multi-Zone Indoor Unit

System Type : Heat Pump
Power Supply : 208-230V/60Hz
Rated Current Cooling : 8.4 A
Rated Current Heating : 10.1 A
Cooling Capacity (Min-Max) : 24,000 Btu/h
Heating Capacity (Min-Max) : 25,000 Btu/h
SEER : 20.5 Btu/w
HSPF4 : 10 Btu/w
HSPF5 : 8.3 Btu/w
COP : 3.17 W/W
Air Flow : 618/471/324 CFM
Noise level - Hi/Mi/Lo : 47.5/42/33 dB(A)
Indoor unit dimension (WxHxD) : 42.52x8.90x13.19 inches
Net/Gross Weight : 29.1/37.0 lbs


Our Services

Genie Air Conditioning and Heating Inc. is the biggest wholesale distributor of mini split systems, air conditioners and heaters in the country.
We carry Air Conditioners in many different sizes and BTUs to meet the needs of our customers. We also carry EXCLUSIVE Cooper & Hunter mini split systems such as the "SOPHIA" Series Single-Zone Mini Split units along with the Multi-Zone models you will find on this page. To find more information about the "Sophia" Series Multi-Zone Mini Split systems we have for sale, check out our main website by clicking the link below!
